BGA PCB Assembly Service

JHYPCB offers one-stop BGA PCB fabrication and assembly services, including BGA soldering and reworks.

Best BGA PCB Assembly Service Manufacturer

BGA is an acronym for Ball Grid Array. It is a terminology used in describing surface mount packaging when circuit boards are being integrated. Are you into the production/manufacturing of high-performance devices? Do you know that not every type of PCB assembly option can prove perfect for such process? This is probably why you need the services of a company like JingHongYi PCB (HK) Co., Limited to handle such process in the most effective manner. Over the years, we have proven to be one of the best and most reliable BGA PCB assembly suppliers around.

What you need to know

Top Facts About PCB BGA Assembly

Faucibus vestibulum mi adipiscing phasellus sagittis fringilla potenti volutpat quam elit fermentum, viverra faucibus ante fringilla.


It has been discovered that many people lack in-depth knowledge and understanding about what PCB bga assembly actually entails. If you are one of such persons, there is no need being worried since you have come to the right place. The mission of JHYPCB is not just about being the best bga PCB assembly manufacturer. It is also our duty to ensure you have the right knowledge about PCB bga assembly. This will help you know the right when time such process is required.


BGA is a form of packaging that is based on surface mount. Its primary usage is meant for circuits which are integrated. One device where a BGA packaging is required is microprocessor. It should be noted this is a crucial surface mount packaging based on the role it plays. For instance, the PCB layout will have additional room/space. In other words, it ensures reduced packaging. This then allows more functions on one chip module. With BGA assembly, it is possible for more interconnection pins to be used on a flat package or dual-inline package.


It should also be noted that BGA has different components. Each of these tends to be different when it comes to packaging materials. Some of these components are ceramic ball grid array (CBGA), ceramic column grid array (CCGA), plastic ball grid array (PBGA), tape ball grid array (TBGA), and chip-scale package (CSP). There is something you need to understand. This is the fact that not every BGA PCB assembly supplier is capable of meeting your expectations.


In fact, the process of PCB bga assembly is so complex and technical that you need a company which is vastly experienced. This is the only way that something won’t go wrong. With what we have done for customers in the past, there is no doubt that you will get nothing but the best services related to PCB bga assembly.

Our PCB Bga Assembly Capabilities

Do you have a complex BGA PCB design? Are you aware that such needs a company that is highly knowledgeable and experienced in handling projects like these? At JHYPCB, we have what it takes to bring any PCB design of your choice into reality. This is possible due to our professionals. The truth is that BGA circuit board assembly has numerous advantages. These could be ensuring that higher density circuits are assembled professionally. They are also perfect for heat conduction and lower inductance.

The problem is that hiring the wrong company can make you not to experience these benefits. This is why you need an experienced BGA PCB assembly supplier like JHYPCB. Our experts have got the required knowledge and experience to render the best of services. They understand what is required for a successful assembly process to be carried out without any compromise.

BGA PCB Assembly Service

Why Trust Our PCB BGA Assembly Services

There are many reasons why you should trust our PCB BGA Assembly services at JHYPCB. For instance, we have succeeded in handling different kinds of BGA PCB assemblies in the past. Over the years, we managed to earn lots of positive reviews from our customers.

Also, we render different services related to leadless BGAs. These could be Micro Ball Grid Array, CTBGA (Thin Chip Array Ball Grid Array), land grid array, Very Fine Pitch Ball Grid Array, Chip scale Package, and Wafer level chip scale packaging. In case you want any of these services, do not hesitate to contact our support team today. We will also make professional recommendations wherever such is necessary.

Furthermore, our experts have carefully laid out plans and approaches to render the best PCB BGA Assembly services. For instance, thermal profile development is what they will start with. In this case, BGA data sheets as well as PCB files you have provided will be reviewed by our experts. This is to ensure the BGA assembly process is executed as planned. Also, be rest assured that voids from solder ball diameter are going to be kept at their barest minimum.  Such is going to be in line with the various government stipulations on Class III or IPC Class II.

Whether you want BGAs that are lead-free or leaded, specialized thermal profiles will be designed. This will ensure that problems related to open balls or extremely high temperatures are avoided. For the sake of accuracy, we ensure that our designs and assembly processes are detailed. Our experts will check surface finishes, solder mask clearances, and maximum warpage. This is to ensure you are getting value for money.

With our professional PCB BGA Assembly services, there is one certain fact – your circuit boards are guaranteed to perform optimally in various appliances where they are used. Your satisfaction is our guarantee thus, we will stop at nothing to render high-quality services. For such to happen, we have various testing and inspecting procedures. These are meant to check whether the assembled circuit boards have errors or any form of problem. Our expert will examine BGA solder connections. The goal is to check for leakages and cracks.

How To Hire Us For PCB BGA Assembly

Given our track record when it comes to rendering professional PCB BGA Assembly services, there is every reason to believe that you have come to the right place. This is because we are capable of rendering services of such nature. In order to get started, feel free to contact us today and specify your needs/expectations. Our expert team will take care of the rest.
